How To Setup An Amazon EKS Demo With Terraform

Since EKS is pretty new, there aren’t a lot of howtos on it yet.

I wanted to follow along with Amazon’s Getting started with EKS & Kubernetes Guide.

However, I didn’t want to use cloudformation. We all know Terraform is far superior!

With that, I went to work getting it going. And a learned a few lessons along the way.

Steps to Setup an Amazon EKS Demo with Terraform

My steps follow pretty closely with the Amazon guide above, and setting up the guestbook app. The only big difference is I’m using Terraform.

Step 1: Create the EKS Service Role

Create a file called eks-iam-role.tf and add the following:

resource "aws_iam_role" "demo-cluster" {  name = "terraform-eks-demo-cluster"
  assume_role_policy = --POLICY{  "Version": "2012-10-17",  "Statement": [    {      "Effect": "Allow",      "Principal": {        "Service": "eks.amazonaws.com"      },      "Action": "sts:AssumeRole"    }  ]}POLICY}
resource "aws_iam_role_policy_attachment" "demo-cluster-AmazonEKSClusterPolicy" {  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSClusterPolicy"  role       = "${aws_iam_role.demo-cluster.name}"}
resource "aws_iam_role_policy_attachment" "demo-cluster-AmazonEKSServicePolicy" {  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSServicePolicy"  role       = "${aws_iam_role.demo-cluster.name}"}

Note: we reference demo-cluster resource. We define that in step #3 below.

Step 2: Create the EKS VPC

Here’s the code to create the VPC. I’m using the Terraform community module to do this.

There are two things to notice here. One is I reference eks-region variable. Add this in your vars.tf. “us-east-1” or whatever you like. Also add cluster-name to your vars.tf.

Also notice the special tags. Those are super important. If you don’t tag your resources properly, kubernetes won’t be able to do it’s thing. Or rather EKS won’t. I had this problem early on and it is very hard to diagnose. The tags in this vpc module, with propagate to subnets, and security groups which is also crucial.

#provider "aws" {  region = "${var.eks-region}"}
#module "eks-vpc" {  source = "terraform-aws-modules/vpc/aws"
  name = "eks-vpc"  cidr = "10.0.0.0/16"
  azs             = "${var.eks-azs}"  private_subnets = "${var.eks-private-cidrs}"  public_subnets  = "${var.eks-public-cidrs}"
  enable_nat_gateway = false  single_nat_gateway = true
  #  reuse_nat_ips        = "${var.eks-reuse-eip}"  enable_vpn_gateway = false
  #  external_nat_ip_ids  = ["${var.eks-nat-fixed-eip}"]  enable_dns_hostnames = true
  tags = {    Terraform                                   = "true"    Environment                                 = "${var.environment_name}"    "kubernetes.io/cluster/${var.cluster-name}" = "shared"  }}
resource "aws_security_group_rule" "allow_http" {  type              = "ingress"  from_port         = 80  to_port           = 80  protocol          = "TCP"  security_group_id = "${module.eks-vpc.default_security_group_id}"  cidr_blocks       = ["0.0.0.0/0"]}
resource "aws_security_group_rule" "allow_guestbook" {  type              = "ingress"  from_port         = 3000  to_port           = 3000  protocol          = "TCP"  security_group_id = "${module.eks-vpc.default_security_group_id}"  cidr_blocks       = ["0.0.0.0/0"]}

Step 3: Create the EKS Cluster

Creating the cluster is a short bit of terraform code below. The aws_eks_cluster resource.

## main EKS terraform resource definition#resource "aws_eks_cluster" "eks-cluster" {  name = "${var.cluster-name}"
  role_arn = "${aws_iam_role.demo-cluster.arn}"
  vpc_config {    subnet_ids = ["${module.eks-vpc.public_subnets}"]  }}
output "endpoint" {  value = "${aws_eks_cluster.eks-cluster.endpoint}"}
output "kubeconfig-certificate-authority-data" {  value = "${aws_eks_cluster.eks-cluster.certificate_authority.0.data}"}

Related: Is Amazon too big to fail?

Step 4: Install & Configure kubectl

The AWS docs are pretty good on this point.

First you need to install the client on your local desktop. For me i used brew install, the mac osx package manager. You’ll also need the heptio-authenticator-aws binary. Again, refer to the aws docs for help on this.

The main piece you will add is a directory (~/.kube) and edit this file ~/.kube/config as follows:

apiVersion: v1clusters:- cluster:    server: https://3A3C22EEF7477792E917CB0118DD3X22.yl4.us-east-1.eks.amazonaws.com    certificate-authority-data: "a-really-really-long-string-of-characters"  name: kubernetescontexts:- context:    cluster: kubernetes    user: aws  name: awscurrent-context: awskind: Configpreferences: {}users:- name: aws  user:    exec:      apiVersion: client.authentication.k8s.io/v1alpha1      command: heptio-authenticator-aws      args:        - "token"        - "-i"        - "sean-eks"      #  - "-r"      #  - "arn:aws:iam::12345678901:role/sean-eks-role"      #env:      #  - name: AWS_PROFILE      #    value: "seancli"%

Step 5: Spinup the Worker Nodes

This is definitely the largest file in your terraform EKS code. Let me walk you through it a bit.

First, we attach some policies to our role. These are all essential to EKS. They’re predefined but you need to group them together.

Then you need to create a security group for your worker nodes. Notice this also has the special kubernetes tag added. Be sure that it there or you’ll have problems.

Then we add some additional ingress rules, which allow workers & the control plane of kubernetes all to communicate with eachother.

Next, you’ll see some serious user-data code. This handles all the startup action, on the worker node instances. Notice we reference some variables here, so be sure those are defined.

Lastly, we create a launch configuration, and autoscaling group. Notice we give it the AMI as defined in the aws docs. These are EKS optimized images, with all the supporting software. Notice also they are only available currently in us-east-1 and us-west-1.

Notice also that the autoscaling group also has the special kubernetes tag. As I’ve been saying over and over, that super important.

## EKS Worker Nodes Resources#  * IAM role allowing Kubernetes actions to access other AWS services#  * EC2 Security Group to allow networking traffic#  * Data source to fetch latest EKS worker AMI#  * AutoScaling Launch Configuration to configure worker instances#  * AutoScaling Group to launch worker instances#
resource "aws_iam_role" "demo-node" {  name = "terraform-eks-demo-node"
  assume_role_policy = --POLICY{  "Version": "2012-10-17",  "Statement": [    {      "Effect": "Allow",      "Principal": {        "Service": "ec2.amazonaws.com"      },      "Action": "sts:AssumeRole"    }  ]}POLICY}
resource "aws_iam_role_policy_attachment" "demo-node-AmazonEKSWorkerNodePolicy" {  policy_arn = "arn:aws:iam::aws:policy/AmazonEKSWorkerNodePolicy"  role       = "${aws_iam_role.demo-node.name}"}
resource "aws_iam_role_policy_attachment" "demo-node-AmazonEKS_CNI_Policy" {  policy_arn = "arn:aws:iam::aws:policy/AmazonEKS_CNI_Policy"  role       = "${aws_iam_role.demo-node.name}"}
resource "aws_iam_role_policy_attachment" "demo-node-AmazonEC2ContainerRegistryReadOnly" {  policy_arn = "arn:aws:iam::aws:policy/AmazonEC2ContainerRegistryReadOnly"  role       = "${aws_iam_role.demo-node.name}"}
resource "aws_iam_role_policy_attachment" "demo-node-lb" {  policy_arn = "arn:aws:iam::12345678901:policy/eks-lb-policy"  role       = "${aws_iam_role.demo-node.name}"}
resource "aws_iam_instance_profile" "demo-node" {  name = "terraform-eks-demo"  role = "${aws_iam_role.demo-node.name}"}
resource "aws_security_group" "demo-node" {  name        = "terraform-eks-demo-node"  description = "Security group for all nodes in the cluster"
  #  vpc_id      = "${aws_vpc.demo.id}"  vpc_id = "${module.eks-vpc.vpc_id}"
  egress {    from_port   = 0    to_port     = 0    protocol    = "-1"    cidr_blocks = ["0.0.0.0/0"]  }
  tags = "${    map(     "Name", "terraform-eks-demo-node",     "kubernetes.io/cluster/${var.cluster-name}", "owned",    )  }"}
resource "aws_security_group_rule" "demo-node-ingress-self" {  description              = "Allow node to communicate with each other"  from_port                = 0  protocol                 = "-1"  security_group_id        = "${aws_security_group.demo-node.id}"  source_security_group_id = "${aws_security_group.demo-node.id}"  to_port                  = 65535  type                     = "ingress"}
resource "aws_security_group_rule" "demo-node-ingress-cluster" {  description              = "Allow worker Kubelets and pods to receive communication from the cluster control plane"  from_port                = 1025  protocol                 = "tcp"  security_group_id        = "${aws_security_group.demo-node.id}"  source_security_group_id = "${module.eks-vpc.default_security_group_id}"  to_port                  = 65535  type                     = "ingress"}
data "aws_ami" "eks-worker" {  filter {    name   = "name"    values = ["eks-worker-*"]  }
  most_recent = true  owners      = ["602401143452"] # Amazon}
# EKS currently documents this required userdata for EKS worker nodes to# properly configure Kubernetes applications on the EC2 instance.# We utilize a Terraform local here to simplify Base64 encoding this# information into the AutoScaling Launch Configuration.# More information: https://amazon-eks.s3-us-west-2.amazonaws.com/1.10.3/2018-06-05/amazon-eks-nodegroup.yamllocals {  demo-node-userdata = --USERDATA#!/bin/bash -xe
CA_CERTIFICATE_DIRECTORY=/etc/kubernetes/pkiCA_CERTIFICATE_FILE_PATH=$CA_CERTIFICATE_DIRECTORY/ca.crtmkdir -p $CA_CERTIFICATE_DIRECTORYecho "${aws_eks_cluster.eks-cluster.certificate_authority.0.data}" | base64 -d >  $CA_CERTIFICATE_FILE_PATHINTERNAL_IP=$(curl -s http://169.254.169.254/latest/meta-data/local-ipv4)sed -i s,MASTER_ENDPOINT,${aws_eks_cluster.eks-cluster.endpoint},g /var/lib/kubelet/kubeconfigsed -i s,CLUSTER_NAME,${var.cluster-name},g /var/lib/kubelet/kubeconfigsed -i s,REGION,${var.eks-region},g /etc/systemd/system/kubelet.servicesed -i s,MAX_PODS,20,g /etc/systemd/system/kubelet.servicesed -i s,MASTER_ENDPOINT,${aws_eks_cluster.eks-cluster.endpoint},g /etc/systemd/system/kubelet.servicesed -i s,INTERNAL_IP,$INTERNAL_IP,g /etc/systemd/system/kubelet.serviceDNS_CLUSTER_IP=10.100.0.10if [[ $INTERNAL_IP == 10.* ]] ; then DNS_CLUSTER_IP=172.20.0.10; fised -i s,DNS_CLUSTER_IP,$DNS_CLUSTER_IP,g /etc/systemd/system/kubelet.servicesed -i s,CERTIFICATE_AUTHORITY_FILE,$CA_CERTIFICATE_FILE_PATH,g /var/lib/kubelet/kubeconfigsed -i s,CLIENT_CA_FILE,$CA_CERTIFICATE_FILE_PATH,g  /etc/systemd/system/kubelet.servicesystemctl daemon-reloadsystemctl restart kubeletUSERDATA}
resource "aws_launch_configuration" "demo" {  associate_public_ip_address = true  iam_instance_profile        = "${aws_iam_instance_profile.demo-node.name}"  image_id                    = "${data.aws_ami.eks-worker.id}"  instance_type               = "m4.large"  name_prefix                 = "terraform-eks-demo"  security_groups             = ["${aws_security_group.demo-node.id}"]  user_data_base64            = "${base64encode(local.demo-node-userdata)}"
  lifecycle {    create_before_destroy = true  }}
resource "aws_autoscaling_group" "demo" {  desired_capacity     = 2  launch_configuration = "${aws_launch_configuration.demo.id}"  max_size             = 2  min_size             = 1  name                 = "terraform-eks-demo"
  #  vpc_zone_identifier  = ["${aws_subnet.demo.*.id}"]  vpc_zone_identifier = ["${module.eks-vpc.public_subnets}"]
  tag {    key                 = "Name"    value               = "eks-worker-node"    propagate_at_launch = true  }
  tag {    key                 = "kubernetes.io/cluster/${var.cluster-name}"    value               = "owned"    propagate_at_launch = true  }}

Step 6: Enable & Test Worker Nodes

If you haven’t already done so, apply all your above terraform:

$ terraform init$ terraform plan$ terraform applyAfter that all runs, and all your resources are created. Now edit the file “aws-auth-cm.yaml” with the following contents:apiVersion: v1kind: ConfigMapmetadata:  name: aws-auth  namespace: kube-systemdata:  mapRoles: |    - rolearn: arn:aws:iam::12345678901:role/terraform-eks-demo-node      username: system:node:{{EC2PrivateDNSName}}      groups:        - system:bootstrappers        - system:nodes%
Then apply it to your cluster:$ kubectl apply -f aws-auth-cm.yamlyou should be able to use kubectl to view node status:
$ kubectl get nodesNAME                           STATUS    ROLES     AGE       VERSIONip-10-0-101-189.ec2.internal   Ready         10d       v1.10.3ip-10-0-102-182.ec2.internal   Ready         10d       v1.10.3$

Related: Why would I help a customer that’s not paying?

Step 7: Setup Guestbook App

Finally, you can follow the exact steps in the AWS docs to create the app. Here they are again:

$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/redis-master-controller.json$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/redis-master-service.json$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/redis-slave-controller.json$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/redis-slave-service.json$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/guestbook-controller.json$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/kubernetes/v1.10.3/examples/guestbook-go/guestbook-service.json

Then you can get the endpoint with kubectl:

$ kubectl get services        NAME           TYPE           CLUSTER-IP       EXTERNAL-IP        PORT(S)          AGEguestbook      LoadBalancer   172.20.177.126   aaaaa555ee87c...   3000:31710/TCP   4dkubernetes     ClusterIP      172.20.0.1                    443/TCP          10dredis-master   ClusterIP      172.20.242.65                 6379/TCP         4dredis-slave    ClusterIP      172.20.163.1                  6379/TCP         4d$

Use “kubectl get services -o wide” to see the entire EXTERNAL-IP. If that is saying you likely have an issue with your node iam role, or missing special kubernetes tags. So, check on those. It shouldn’t show for more than a minute really.

Conclusion

That’s all about how to setup an Amazon EKS demo with Terraform. Hope you got everything working. Good luck and if you have questions, post them in the comments & I’ll try to help out!
